Hydraulic Winch 8000 LBS

HYDRAULIC WINCH 8000 LBS

Properties

  • High-strength, long-lasting steel body
  • Extra reinforced planetary gear system with special steel heat treatment
  • Lightweight and powerful design
  • 100% negative effective hydraulic disc brake system

  • Standard winch guide system and rope stabiliser

  • Manual winch discharge system provided as standard
  • High torque hydromotor
  • Meets CE-EN 14492-1

Applications : General Industrial, Mining & Construction, Railroad, Specialty Vehicle, Towing & Recovery, Trailer, Utility

Technical Data

Maximum Pulling Force8.000 lbs
Rope Diameter3/8 in
Maksimum Rope Length134 ft
Hydromotor12 ci. (200 cc)
Maximum Pump Flow15.8 GPM
Gear Ratio5/1
Maximum Operating Pressure1740 psi
Recommended Gear Oil80 w 90 (23,6 fl oz)
Weight138 lbs
Clutch Control (Optional)Air or Manual
Speed58 ft/min

Warning!

  • Valve’s a-b line must be opened (which is need to operate the hydraulic winch) otherwise hydraulic brake will release the load
  • Hydromotor leak line must be opened and installed to the oil tank
  • The last 5 winding ropes should always be left on it
  • It is designed and manufactured for winch pulling purposes, do not use it to remove people or materials
Hydraulic Winch 8.000 LBS

Manual

Hydraulic Winch 8.000 LBS

Pneumatic
